Medical Equipment Castors
Sometimes it’s a matter of seconds – the right medication, the appropriate team, and the necessary luck. Fine, at times like this you need the reassurance that the castors from Colson are dependable. We deliver our promises: quiet operation, load-bearing capacity, safety and long product life.
BPAU 1603 6440
BPAU 1603 6440 160 mm - 200 mm, 250 kg
Technical data
| Diameter | 160 mm |
| Wheel width | 50 mm |
| Hub length | 62 mm |
| Height | 195 mm |
| Offset | 60 mm |
| Top plate dimensions | 140 x 110 mm |
| Top plate hole diameter | 10.5 mm |
| Dist. between holes | 105 x 75,80 mm |
| Brake swivel radius | 178 mm |
| Load capacity | 250 kg |
| Weight | 3.1 kg |
Wheel
- Aluminium wheels with bonded-on polyurethane tyre (Shore A 92) with two deep groove ball bearings and steel collar bushes external diameter 15/20/25 mm to internal 8/10/12 mm. Operating temperatures from -20°C to + 80°C
Technical description
- Swivel fork of deep drawn zinc-coated steel,
- swivel bearing with double ball race way and sealring (excluded the bolt hole fixing plate) with a total lock brake
