Medical Equipment Castors

Sometimes it’s a matter of seconds – the right medication, the appropriate team, and the necessary luck. Fine, at times like this you need the reassurance that the castors from Colson are dependable. We deliver our promises: quiet operation, load-bearing capacity, safety and long product life.

JSCP 1803 6443/B 160 mm - 250 mm, 285 kg - 445 kg

Technical data

Diameter 180 mm
Wheel width 50 mm
Hub length 64 mm
Height 225 mm
Offset 60 mm
Wheel axle diameter 20 mm
Top plate dimensions 135 x 112 mm
Top plate hole diameter 11 mm
Dist. between holes 105 x 75,80 mm
Brake swivel radius 145 mm
Load capacity 320 kg
Weight 5.4 kg
Reach compliant Rohs compliant

Wheel

  • Cast iron wheel with pressed-on full-elastic rubber tyre
  • (Shore A 68) with two deep groove ball bearings

Technical description

  • Swivel fork of deep drawn zinc-coated steel with wheel brake. Swivelhead with sealed precision
  • ball bearing and a grease nippel
