Stainless Steel Castors

In the age of high technology the latest hygiene regulations shape the climate in laboratories for biotechnology, medicine and food research. Cleanliness is an essential part of quality management. Stainless steel castors from Colson are dazzling with their outstanding properties for this kind of environment. Produced from high-quality pure steel and precisely manufactured, they bring sterilising and instrument cabinets and other mobile units safe and clean to their destination.

FPPN 1001 5000


FPPN 1001 5000 80 mm - 125 mm, 150 kg - 200 kg

Technical data

Diameter 100 mm
Wheel width 35 mm
Hub length 42 mm
Height 128 mm
Offset 38 mm
Wheel axle diameter 8 mm
Top plate dimensions 105 x 85 mm
Top plate hole diameter 9.6 mm
Dist. between holes 80 x 60 mm
Brake swivel radius 128 mm
Load capacity 150 kg
Weight 0.7 kg
Reach compliant Rohs compliant

Wheel

  • Polyamide wheel with one sealed deep groove ball bearing

Technical description

  • Rigid fork of zinc-coated sheet steel
