Transport Appliance Castors

The global world of networking is shaping new demands on logistics and the transport business. Mobility is being understood in a new way. Not only across national borders, but in the internal flow of goods. Castors from Colson are solid and reliable components within this agile cycle. They move trolleys, workbenches, switch cabinets, cleaning equipment and other mobile facilities – and have just one goal in the process: to guarantee quality – forever.

BVPN 0751 1100 (Barracuda "PN")

441h 00R080p ZPH 75 mm, 400 kg

Technical data

Diameter 75 mm
Tread width 37 mm
Height 110 mm
Offset 40 mm
Top plate dimensions 105x86 mm
Top plate hole diameter 9 mm
Dist. between holes 80/77x60 mm
Load capacity 400 kg
Reach compliant Rohs compliant

Wheel

  • polyamide white
  • plain bearing

Technical description

  • Stable sheet steel design and proven technology
  • Easy running double ball bearing for good manoeuvrability

Areas of application

  • assembly dolly
  • creeper dolly
  • magazine carts
  • tool trolleys
  • transport containers
  • transport trolleys
  • waste disposal containers
