Wheels & Accessories
The composition of the tyre and the various types of wheel rims or hubs as well as various wheel bearings give the wheel many different properties. Because of this wheels have differing load capacities, resistance to rolling and operational qualities.
BXPR 1255 5000
BXPR 1255 5000 80 mm - 125 mm, 120 kg - 180 kg
Technical data
| Diameter | 125 mm |
| Wheel width | 40 mm |
| Hub length | 45 mm |
| Height | 156 mm |
| Offset | 41 mm |
| Bolt hole diameter | 12 mm |
| Brake swivel radius | 138 mm |
| Load capacity | 180 kg |
| Weight | 1.2 kg |
Wheel
- Dark grey Polypropyleene wheel with a blue elasticrubber tyre (Performa, Shore A 65 - 70) with one deep groove ball bearing
Technical description
- Swivel fork of deep drawn stainless steel
- Swivel bearing with double ball race and sealring
- with a total lock brake
