362a 36K125b ZLD
362a 36K125b ZLD 125 mm, 100 kg
Technical data
| Diameter | 125 mm |
| Tread width | 32 mm |
| Height | 155 mm |
| Offset | 38 mm |
| Bolt hole diameter | 12,2 mm |
| Load capacity | 100 kg |
| Weight | 720 g |
Wheel
- solid rubber tyre iron-grey RAL 7011 (Shore A 80)
- plastic wheel centre and plastic thread guard silver grey RAL 7001
- precision ball bearing
Technical description
- sheet steel metal
- swivel bearing with double ball race
- zinc passivated
- also available with bolt hole LC (10,2 mm)
- on inquiry also available with threaded (ZGI) and flat pin (ZCS)
Areas of application
- cleaning equipment
- display stands
- restaurant areas
- laundry carts
- food transport equipment
- catering trolleys
- housekeeping carts
- shopping trolleys
- dustbins
- wet and dry vaccum cleaners
- brochure display stands
- sales stands
36304 - MM 125 CHOCK PIV AR RED (Mallmaster)
125 mm, 60 kg
Technical data
| Diameter | 125 mm |
| Tread width | 30 mm |
| Height | 150 mm |
| Offset | 43 mm |
| Load capacity | 60 kg |
Wheel
- Polyamide differential wheel with polyurethane tyre
- Hard rubber brake ring
- Ball bearing
Technical description
- Sheet steel housing
- galvanised-passivated
- Swivel bearing with double-row ball race
- Choc-fitting
- Also available with another fitting options
Areas of application
- Shopping trolleys (moving walkways)
36305 - MM 125 CC 12X15 AV RED (Mallmaster)
125 mm, 60 kg
Technical data
| Diameter | 125 mm |
| Tread width | 30 mm |
| Height | 155 mm |
| Offset | 43 mm |
| Threaded stem size | 12x15 mm |
| Load capacity | 60 kg |
Wheel
- Polyamide differential wheel with polyurethane tyre
- Hard rubber brake ring
- Ball bearing
Technical description
- Sheet steel housing
- galvanised-passivated
- Swivel bearing with double-row ball race
- Also available with another fitting options
Areas of application
- Shopping trolleys (moving walkways)
36307 - MM 125 OEIL (Mallmaster)
125 mm, 60 kg
Technical data
| Diameter | 125 mm |
| Tread width | 30 mm |
| Height | 155 mm |
| Offset | 40 mm |
| Bolt hole diameter | 12 mm |
| Load capacity | 60 kg |
Wheel
- Polyamide differential wheel with polyurethane tyre
- Hard rubber brake ring
- Ball bearing
Technical description
- Sheet steel housing
- galvanised-passivated
- Swivel bearing with double-row ball race
- Also available with another fitting options
Areas of application
- Shopping trolleys (moving walkways)
36308 - MM 125 OEIL (Mallmaster)
125 mm, 60 kg
Technical data
| Diameter | 125 mm |
| Tread width | 30 mm |
| Height | 155 mm |
| Offset | 40 mm |
| Bolt hole diameter | 12 mm |
| Load capacity | 60 kg |
Wheel
- Polyamide differential wheel with polyurethane tyre
- Hard rubber brake ring
- Ball bearing
Technical description
- Sheet steel housing
- galvanised-passivated
- Swivel bearing with double-row ball race
- Also available with another fitting options
Areas of application
- Shopping trolleys (moving walkways)
363b 62C125v ZLD
On request
363b 62C125v ZLD 125 mm, 60 kg
Technical data
| Diameter | 125 mm |
| Height | 150 mm |
| Offset | 43 mm |
| Bolt hole diameter | 12,2 mm |
| Load capacity | 60 kg |
| Weight | 838 g |
Wheel
- polyamid differential wheel with raceway of polyurethane
- black hard rubber brake ring
- ball bearing
Technical description
- sheet steel metal housing
- swivel bearing with double ball race
- zinc passivated
- also available with bolt hole LC (10,2 mm)
- on inquiry also available with threaded (ZGI) and flat pin (ZCS)
Areas of application
- Shopping trolleys
- (autowalk)
363b 810 7575-1
On request
363b 810 7575-1 125 mm, 60 kg
Technical data
| Diameter | 125 mm |
| Height | 150 mm |
| Offset | 43 mm |
| Bolt hole diameter | 12,2 mm |
| Load capacity | 60 kg |
| Weight | 644 g |
Wheel
- polyamid differential wheel with raceway of polyurethane
- black hard rubber brake ring
- ball bearing
Technical description
- sheet steel metal housing
- swivel bearing with double ball race
- zinc passivated
- also available with bolt hole LC (10,2 mm)
- on inquiry also available with threaded (ZGI) and flat pin (ZCS)
Areas of application
- Shopping trolleys
- (autowalk)
363b68K125vZLD_B
On request
125 mm, 80 kg
Technical data
| Diameter | 125 mm |
| Height | 150 mm |
| Offset | 43 mm |
| Bolt hole diameter | 12,2 mm |
| Load capacity | 80 kg |
Technical description
- sheet steel metal housing
- swivel bearing with double ball race
- zinc passivated
- also available with bolt hole LC (10,2 mm)
- on inquiry also available with threaded (ZGI) and flat pin (ZCS)
Areas of application
- (autowalk)
- Shopping trolleys
367h 31CA-32 ZLD
80 mm, 100 kg
Technical data
| Diameter | 80 mm |
| Tread width | 32 mm |
| Height | 110 mm |
| Offset | 43,5 mm |
| Bolt hole diameter | 12,2 mm |
| Load capacity | 100 kg |
| Weight | 630 g |
Wheel
- TPE tread electr.-conductive (Shore A 87)
- polypropylene wheel body
- thread guard
- ball bearing
- non-oiling
- on request further variants available
Technical description
- sheet steel metal housing
- zinc passivated
- swivel bearing with double ball race
- protected from dust and water spray with plastic seal
- available with plate PD (77x67 mm) and PF (95x70 mm)
- available with bolt hole LC (10,2 mm) and LD (12,2 mm)
- on inquiry also available with fixing pin Z522 (24x45 mm) and Z622 (28x45 mm)
Areas of application
- Laundry carts
- brochure display stands
- care beds
- cleaning equipment
- computer area
- display stands
- dustbins
- file carts
- food transport equipment
- housekeeping carts
- industrial kitchen equipment
- industrial kitchens
- laundry
- medical equipment
- medical-technical equipment
- newspaper dispensers
- occasional carts
- restaurant area
- restaurant areas
- sales stands
- shop fittings
- sport equipment
- tripods
- waste containers
36K125b
36K125b 125 mm, 100 kg
Technical data
| Diameter | 125 mm |
| Tread width | 33 mm |
| Hub length | 36,5 mm |
| Wheel axle diameter | 8 mm |
| Load capacity | 100 kg |
Wheel
- solid rubber tyre iron-grey RAL 7011 (Shore A 80)
- plastic wheel centre and plastic thread guard silver grey RAL 7001
- precision ball bearing
