381a 40K075v KGD
On request
381a 40K075v KGD 75 mm - 125 mm, 75 kg - 110 kg
Technical data
| Diameter | 75 mm |
| Tread width | 59/2x10 mm |
| Height | 95 mm |
| Threaded stem size | M12x25 mm |
| Load capacity | 75 kg |
Technical description
- plastic castor
- wheels have easy rollability
- the design protects axle / bearing areas from hair / water
- total lock models lock both the wheel and swivel
- also available wheel diameter 125 mm with fixing pin K622 (28x45 mm)
Areas of application
- diagnostic equipment
- electronic equipment
- medical equipment
- care beds
- patient lifts
381a 40K075v KPS
On request
381a 40K075v KPS 75 mm - 125 mm, 75 kg - 110 kg
Technical data
| Diameter | 75 mm |
| Tread width | 59/2x10 mm |
| Height | 105 mm |
| Top plate dimensions | 94X64 mm |
| Top plate hole diameter | 8,5 mm |
| Dist. between holes | 78/72X45 mm |
| Load capacity | 75 kg |
Technical description
- plastic castor
- wheels have easy rollability
- the design protects axle / bearing areas from hair / water
- total lock models lock both the wheel and swivel
- also available wheel diameter 125 mm with fixing pin K622 (28x45 mm)
Areas of application
- diagnostic equipment
- electronic equipment
- medical equipment
- care beds
- patient lifts
381h 40K075v KGD
On request
381h 40K075v KGD 75 mm - 125 mm, 75 kg - 110 kg
Technical data
| Diameter | 75 mm |
| Tread width | 59/2x10 mm |
| Height | 95 mm |
| Threaded stem size | M12x25 mm |
| Load capacity | 75 kg |
Technical description
- plastic castor
- wheels have easy rollability
- the design protects axle / bearing areas from hair / water
- total lock models lock both the wheel and swivel
- also available wheel diameter 125 mm with fixing pin K622 (28x45 mm)
Areas of application
- diagnostic equipment
- electronic equipment
- medical equipment
- care beds
- patient lifts
381h 40K075v KPS
On request
381h 40K075v KPS 75 mm - 125 mm, 75 kg - 110 kg
Technical data
| Diameter | 75 mm |
| Tread width | 59/2x10 mm |
| Height | 105 mm |
| Top plate dimensions | 94X64 mm |
| Top plate hole diameter | 8,5 mm |
| Dist. between holes | 78/72X45 mm |
| Load capacity | 75 kg |
Technical description
- plastic castor
- wheels have easy rollability
- the design protects axle / bearing areas from hair / water
- total lock models lock both the wheel and swivel
- also available wheel diameter 125 mm with fixing pin K622 (28x45 mm)
Areas of application
- diagnostic equipment
- electronic equipment
- medical equipment
- care beds
- patient lifts
383q 40K150v K985
On request
383q 40K150v K985 125 mm - 150 mm, 120 kg - 150 kg
Technical data
| Diameter | 150 mm |
| Tread width | 64 mm |
| Height | 175 mm |
| Offset | 40 mm |
| Load capacity | 150 kg |
Wheel
- thermoplastic polyurethane tyre (TPU, Shore A 95)
- free of contact discoloration
- precision ball bearing
Technical description
- plastic housing of polyamide white RAL 9010
- precision ball bearings in the fork head
- suitable for cleaning in disinfecting cubicles
- smooth selection function
- integrated selection mechanism with total locking brake "q"
- and directional locking brake "r"
- selection mechanism continually greased
- on inquiry with electrically conductive wheel
Areas of application
- care beds
- hospital beds
- intensive care beds
- medical & diagnostic equipment
- medical-technical equipment
- op beds
- op tables
391q 29K100r Z2351ZA
391q 29K100r Z2351 100 mm - 200 mm, 100 kg - 120 kg
Technical data
| Diameter | 100 mm |
| Tread width | 30 mm |
| Height | 139 mm |
| Offset | 42 mm |
| Stem size | 28x100 (41°/52°) mm |
| Load capacity | 100 kg |
Wheel
- thermoplastic elastomer tyre (TPE) iron grey RAL 7011 (Shore A 80)
- plastic wheel centre and thread guard silver grey RAL7001
- precision ball bearing
- Contact discoloration on unsealed grounds possible!>>
Technical description
- sheet steel metal housing
- zinc passivated
- presicion ball bearing in swivel head
- protected from dust and water ingress by plastic sealing ring
- integrated selection mechanism with total locking brake "q"
- and directional locking brake "r"
- selection mechanism continually greased
- device to permit adjustment of the braking effect
- (without removing the castor or wheel)
- also available with other wheel variants
Areas of application
- care beds
- hospital beds
- intensive care beds
- medical equipment
- op beds
- op tables
391q 29K100r Z985NP
391q 29K100r Z985 100 mm - 200 mm, 100 kg - 120 kg
Technical data
| Diameter | 100 mm |
| Tread width | 30 mm |
| Height | 139 mm |
| Offset | 42 mm |
| Stem size | 32x50 (30°) mm |
| Load capacity | 100 kg |
Wheel
- thermoplastic elastomer tyre (TPE) iron grey RAL 7011 (Shore A 80)
- plastic wheel centre and thread guard silver grey RAL7001
- precision ball bearing
- Contact discoloration on unsealed grounds possible!>>
Technical description
- sheet steel metal housing
- zinc passivated
- presicion ball bearing in swivel head
- protected from dust and water ingress by plastic sealing ring
- integrated selection mechanism with total locking brake "q"
- and directional locking brake "r"
- selection mechanism continually greased
- device to permit adjustment of the braking effect
- (without removing the castor or wheel)
- also available with other wheel variants
Areas of application
- care beds
- hospital beds
- intensive care beds
- medical equipment
- op beds
- op tables
391q 32C100b Z2351ZA
391q 32C100b Z2351 100 mm - 200 mm, 80 kg - 120 kg
Technical data
| Diameter | 100 mm |
| Tread width | 32 mm |
| Height | 139 mm |
| Offset | 42 mm |
| Stem size | 28x100 (41°/52°) mm |
| Load capacity | 80 kg |
Wheel
- solid rubber tyre blue-grey (Shore A 80)
- sheet steel metal rim zinc passivated
- metal thread quard
- flange bearing
Technical description
- sheet steel metal housing
- zinc passivated
- presicion ball bearing in swivel head
- protected from dust and water ingress by plastic sealing ring
- integrated selection mechanism with total locking brake "q"
- and directional locking brake "r"
- selection mechanism continually greased
- device to permit adjustment of the braking effect
- (without removing the castor or wheel)
- also available with other wheel variants
Areas of application
- care beds
- hospital beds
- intensive care beds
- medical equipment
- op beds
- op tables
391q 32C100b Z985NP
391q 32C100b Z985 100 mm - 200 mm, 80 kg - 120 kg
Technical data
| Diameter | 100 mm |
| Tread width | 32 mm |
| Height | 139 mm |
| Offset | 42 mm |
| Stem size | 32x50 (30°) mm |
| Load capacity | 80 kg |
Wheel
- solid rubber tyre blue-grey (Shore A 80)
- sheet steel metal rim zinc passivated
- metal thread quard
- flange bearing
Technical description
- sheet steel metal housing
- zinc passivated
- presicion ball bearing in swivel head
- protected from dust and water ingress by plastic sealing ring
- integrated selection mechanism with total locking brake "q"
- and directional locking brake "r"
- selection mechanism continually greased
- device to permit adjustment of the braking effect
- (without removing the castor or wheel)
- also available with other wheel variants
Areas of application
- care beds
- hospital beds
- intensive care beds
- medical equipment
- op beds
- op tables
399a 38K150v KPF-FK (NIMBUS)
On request
399a 38K150v KPF-FK 150 mm, 80 kg
Technical data
| Diameter | 150 mm |
| Tread width | 32 mm |
| Height | 201 mm |
| Offset | 42 mm |
| Top plate dimensions | 95x70 mm |
| Top plate hole diameter | 9 mm |
| Dist. between holes | 75x45/72x52 mm |
| Load capacity | 80 kg |
Technical description
- die-cast aluminium load-bearing housing
- highly polished plastic cover white RAL 9016
- unique design and patented technology
- precision ball bearings in the fork head
Areas of application
- medical equipment
- furniture
